Question 2

Question 2

Parallel-Axis Theorem question 2

Find I_x̄-x̄ first, then calculate I_x-x using the parallel-axis theorem.

Find I_x̄-x̄ first, then calculate I_x-x using the parallel-axis theorem.

Click below to show answer. X

Step 1:
Calculate I_x̄-x̄

Step 1:
Calculate I_x̄-x̄

Parallel-Axis Theorem solution step 1

Step 2:
Use parallel-axis theorem to find I_x-x

Step 2:
Use parallel-axis theorem to find I_x-x

Parallel-Axis Theorem solution step 2

Useful formula:

Useful formula:

Parallel-Axis Theorem formula

Congratulations! You've completed all the questions in this topic. Let's look at C5: Internal Forces and Beams now.
